PhysioMill

The PhysioMill rehabilitation treadmill has a heavy duty 4 HP Hi-Torque DC Servo motor specifically designed to offer a true zero start with .10 mph increments for patients up to 500 lbs., with speeds up to 15 mph.

The extremely versatile PhysioMill rehabilitation treadmill has a reverse belt mode with 15 percent elevation allowing for downhill negative walking. The 500 lb. weight capacity and the 21” x 63” walking belt allows the PhysioMill to be used in a variety of clinical settings such as Neurological, Orthopedic, Sports Medicine, Cardiac Rehab, Bariatrics and Pediatrics.

The PhysioMill rehabilitation treadmill comes standard with; short handrails, dual emergency stop buttons, hand held remote start/stop/pause, orthopedic walking belt and contact heart rate. The PhysioMill may be the last rehabilitation treadmill you will ever need to purchase. “Over built and built to last!”

Videos

Specifications

PhysioMill
Technical Details
Drive System 4 HP Continuous-Duty DC Servo Motor
Belt Direction Foward and Reverse Direction
Running Surface 21" W x 63" L (53.3cm x 160 cm)
Treadmill Deck Four-Ply ErgoDeck Shok Absorption System with Reversible Deck
Treadmill Rollers 3.5" (8.9 cm), 22 lbs (10 kg) Steel Rollers
Speed Forward 0.1 - 12 MPH (0 - 19.2 kph)*True Zero Start
Speed Backward 0.1 - 3 MPH (0 - 4.8 kph) *True Zero Start
Speed Increments 0.1 Speed Adjustment Increments
Incline Range -15% to +15%
Max User Weight 500 lbs.
Deck Height Only 6.25" (16.5 cm) Step-Up
Emergency Stop Dual Emergency Stop Buttons & Safety Lanyard
Hand-Held Remote Therapist Start-Stop
Isolation Less than 100 Mirco Amps Standard
Domestic Power 120 VAC, 60Hz, 15 A
International Power 220 VAC, 50/60Hz, 15 A
Product Type Commercial Grade
Treadmill Model # TMR
Short Handrail Kitl #
*Optional		 TMR-HR
Computer Details
Display High Definition 9" LCD Display
Programs 12 Set Programs
Backlight Easy to Read High Contrast Blue
Feedback Speed, Time, Distance, Grade, Pulse, Calories, METS & Reverse
Heart Rate Contact Heart Rate on Seat Handles & Built in Receiver Compatible with Polar and other Manufactures
*Chest Belt Not Included
*Light Instiutional Warranty
Frame Lifetime
Motor 5 Years
Tread Belt 5 Years
Mechanical & Electronic Parts 5 Years
Wearable Parts 1 Year
Labor 1 Year
Shipping & Assembly
Shipping Freight
Assembly Required Support Arms, Display, Side Rails
Unit Dimensions
Compact Dimensions 81" L X 30.5" W X 54" H
W/ Medical Handrails 87" L x 36" W x 54" H
Unit Weight 345 lbs.
