Introducing the OmniTrainer® Active and Passive Total Body Trainer with bio-feedback software by HealthCare International. Equipped with 3 training modes: Active, Passive and Passive-Assist training the OmniTrainer® specifically designed for physical and neurological rehabilitation exercises. In Passive Mode the OmniTrainer provides smooth and powerful forced exercise assistance to the user.

The durable AC motors allow users to select bi-directional motorized speeds up to 60 RPM in 1 RPM increments. In Active Mode, resistance can be adjusted by increments of 1 up to level 18 for either Upper or Lower body training. Smooth bi-directional resistance allows for increased muscle activation. The Left vs Right bio-feedback graph in Active Mode provides visual feedback of the user’s lateral power output so that the they can focus on symmetric pedaling. OmniSense Technology allows for sessions to utilize both Passive and Active training modes. Workout plans can be customized providing various passive-assistance to the user. RPM and power levels can be adjusted so that the OmniTrainer will automatically change between active and passive modes.

Starting in passive mode, the OmniTrainer will automatically change to Active Mode if the user is able to exceed the set RPM level. The percentage of Passive and Active Training is displayed in a graph to encourage the user and promote active training. The OmniTrainer is portable and can be used with either a standard chair or a wheelchair.

The OmniTrainer is adjustable to fit a wide range of users. Height adjustable upper body section, ergonomic u-shaped handles, extra-wide pedals, adjustable cranks, and oscillating calf supports, helps securely fit users at various ability levels. The workout report function allows users to track their progress displaying total time, total distance, number of spasm, percent Active vs Passive training, and percent Left vs Right Power at the end of the training session. The OmniTrainer Active and Passive Trainer’s versatility and durability makes it an ideal piece of equipment to be used in any stage of rehabilitation.



Technical Details
Active Resistance


Passive Assistance


OmniSense Active Assist
Adjusts to User Activity Rate


Resistance Levels 1 - 15
Motor-Assist 1 - 60 RMP
Arm Adjustment Swivel and Up/Down
Pedals Heal Cup + Leg Support
Max User Weight Unlimited
Power AC 110V | 60Hz
Product Type Commercial Grade
Model # OT-1100
Computer Details
Display Large Color LCD Display
BioFeedback Symmetry Training / Activity Level
Workout Feedback Speed, Time, Distance, Spasm Count
Workout Report


Voice Guidance


Frame Lifetime
Mechanical Parts 1 Year
Electronic Parts 1 Year
Shipping & Assembly
Shipping LTL
Assembly Required Fully Assembled
Unit Dimensions
Compact Dimensions 23-36" L x 24" W x 43-48"H
Unit Weight 88 lbs
